Motorola MOTOTRBO ISR5 UHF Intrinsically Safe Two-Way Radio with Display

Motorola MOTOTRBO R5 UHF intrinsically safe portable two-way radio with display.

Who it is for

The MOTOTRBO R5 is Motorola's compact digital portable for teams that work around noise: Motorola positions it on loud, clear audio that cuts through background noise, status indications a user can read without stopping, and a body sealed to IP67 and tested to MIL-STD 810. CMI lists it for warehouses, logistics, operations and hospital teams. This is the display model with a limited keypad: a 1.5 inch 132 x 48 pixel monochrome screen, 256 channels in 50 zones and 5 programmable buttons. It is the UHF model, which suits buildings and built-up sites; read UHF vs VHF two-way radios if the band choice is still open, and analog vs digital two-way radios if digital radio is new to the site.

Hazardous-location rating

Motorola's R5 data sheet states the rating in these words: ANSI/TIA4950 and CAN/CSA C22.2 No. 157-92 certified as intrinsically safe for use in Class I, II, III, Division 1, Groups C, D, E, F, G, Division 2, Groups A, B, C, D when properly equipped with Motorola UL-Approved battery. The rating depends on the radio being equipped with the UL-approved battery (the TIA4950 PMNN4890) and the approved accessories; the label on the radio is the authority for the exact approval it carries. Confirm the complete approved configuration with CMI before you order.

Size, weight and battery

• Battery and runtime: the UL-approved 3200 mAh IMPRES Li-Ion TIA4950 battery (PMNN4890) is the battery Motorola names for this rating: 30 hours digital or 23 hours analog on a 5-5-90 duty cycle at maximum transmitter power with Bluetooth and Wi-Fi off; observed runtimes vary.
• Size and weight: 122 x 56 x 41 mm (4.82 x 2.2 x 1.6 in) and 332 g (11.7 oz) with the TIA4950 battery.
• Power and band: 4 W high and 1 W low on 400 to 512 MHz, 12.5 or 25 kHz channel spacing, DMR Tier II digital and analog.
• Audio: 1 W rated and 3 W maximum audio output; 101 phon at 30 cm by default and, in digital mode, up to 106 phon at 30 cm with the user-selectable audio profile; SINC+ single-microphone noise cancellation and AI-trained noise suppression.
• Connectivity: Wi-Fi 5 (802.11 a, b, g, n and ac) on 2.4 and 5 GHz with WPA3 and WPA2, 128 SSIDs; Bluetooth 5.2, class 2, 10 m; over-the-air programming over DMR and software updates over Wi-Fi; slim GCAI accessory port.
• Safety features: emergency button and lone worker; canned text messaging.
• Protection: IP67 against dust and water immersion, tested to MIL-STD 810 C through H; radio operating temperature -22 F to 140 F (-30 C to +60 C), battery minimum -20 C.
• Service: Motorola includes hardware repair, technical support and software updates for 5 years.

Licence

This radio operates on licensed business frequencies. An FCC business radio licence (Part 90) is required to transmit; CMI can point you at the process when you order.

Accessories that fit

CMI connector code: M15 (the R5 slim GCAI port). Motorola's R5 data sheet names the PMNN4888 2200 mAh, PMNN4889 3200 mAh and PMNN4890 TIA4950 3200 mAh IMPRES batteries. Ask CMI for an earpiece, headset or speaker microphone for this radio by connector code M15.

Part number

CMI part number: ISR5-U-DISPLAY. Related configurations: the ISR5 UHF non-display model and the standard R5 UHF display radio. See CMI's Motorola collection and two-way radio collection.

How to order

This radio is a special order. Pricing is not published for this item; call CMI at (310) 753-0991 for a quote and we will confirm the configuration and the price before you order.
